LENOVO ThinkPad X9 G1 Intel U5-228V 32GB DDR5 RAM 512GB M.2 2242 PCIe SSD Arc Graphics Win11 PRO 15.3" 21Q6003SAU Notebook

LENOVO ThinkPad X9 G1 15.3" 2.8K OLED Intel U5-228V 32GB DDR5 512GB SSD Windows 11 PRO Arc Graphics NPU 40 TOPS Fingerprint Thunderbolt 3YR PRE 1.4kg

PERFORMANCE
Processor Intel® Core™ Ultra 5 228V, 8C (4P + 4LPE) / 8T, Max Turbo up to 4.5GHz, 8MB
AI PC Category Copilot+ PC

NPU Integrated Intel® AI Boost, up to 40 TOPS
Graphics Integrated Intel® Arc™ Graphics 130V

Chipset Intel® SoC Platform
Memory 32GB Soldered LPDDR5x-8533, MoP Memory
Memory Slots Memory soldered to systemboard, no slots, dual-channel
Max Memory 32GB soldered memory, not upgradable

Storage 512GB SSD M.2 2242 PCIe® 4.0x4 NVMe® Opal 2.0
Storage Support One drive, up to 2TB M.2 2242 SSD
Storage Slot One M.2 2242 PCIe® 4.0 x4 slot

Card Reader None
Audio Chip High Definition (HD) Audio, Cirrus Logic® CS42L43

Speakers Stereo speakers, 2W x2 woofers and 2W x2 tweeters, Dolby Atmos®
Camera UHD 8.0MP with Large Sensor + IR Discrete, with E-Shutter, ToF Sensor, MIPI

Microphone 2x, Array
Battery Integrated 80Wh

Power Adapter 65W USB-C® Slim GaN (3-pin)
DESIGN

Display 15.3" 2.8K (2880x1800) OLED 500nits Anti-reflection / Anti-fingerprint, 100% DCI-P3, 30-120Hz VRR, DisplayHDR™ True Black 600, Dolby Vision®
Touchscreen None

Color Calibration Factory Color Calibration
Keyboard Backlit, English
Touchpad Haptic Touchpad

Case Color Grey
Case Material Aluminium (Top), Aluminium (Bottom)
Pen Pen Not Supported

Dimensions (WxDxH) 339.55 x 228.5 x 12.9 mm (13.37 x 9.0 x 0.51 inches)
Weight Starting at 1.4 kg (3.08 lbs)
SOFTWARE

Operating System Windows® 11 Pro, English (US) / English (UK)
Bundled Software Intel® Connectivity Performance Suite + Lenovo® AI Now

CONNECTIVITY
Ethernet No Onboard Ethernet
WLAN + Bluetooth Intel® Wi-Fi® 7 BE201, 802.11be 2x2 + BT5.4
WWAN Non-WWAN

SIM Card None
NFC None
Standard Ports 1x USB-A (USB 10Gbps / USB 3.2 Gen 2), Always On
2x USB-C® (Thunderbolt™ 4 / USB4® 40Gbps), with USB PD 3.0 and DisplayPort™ 2.1
1x HDMI® 2.1, up to 4K/60Hz
1x Headphone / microphone combo jack (3.5mm)

Docking Various docking solutions supported via Thunderbolt™. For more compatible docking solutions, please visit Docking for ThinkPad® X9-15 Gen 1

SECURITY & PRIVACY
Smart Card Reader None
Security Chip Discrete TPM 2.0 Enabled

Fingerprint Reader Touch Style, Match-on-Chip, Integrated in Power Button
Other Security ToF Human Presence Detection

E-shutter
IR camera for Windows® Hello (facial recognition)
MANAGEABILITY
System Management Non-vPro®

SERVICE
Base Warranty 1-year, Courier or Carry-in
Included Upgrade 3Y Premier Support Upgrade from 1Y Courier/Carry-in, CO2 Offset 0.5 ton (2nd Generation Carbon Offset Projects)

ACCESSORIES
Bundled Accessories None

CERTIFICATIONS
Green Certifications ENERGY STAR® 8.0
EPEAT™ Gold Registered
ErP Lot 6/26
RoHS compliant

TCO Certified 10.0
Other Certifications Eyesafe® Certified 2.0
Intel® Evo™ Platform
TÜV Rheinland® Eye Comfort Certification (5-star)
Mil-Spec Test MIL-STD-810H military test passed
