Gigabyte B650I AX AM5 Mini-ITX DDR5 Motherboard

Gigabyte B650I AX AM5 Mini-ITX Motherboard - Chipset: AMD B650 - Socket: AMD Socket AM5 - Memory: 2x DDR5 (Up to 96GB, 6400MHz OC) - Expansion Slots: 1x PCIe 4.0 x16 - Storage: 2x SATA, 1x M.2 PCIe 4.0 x4 - I/O: 1x DisplayPort, 1x HDMI, 1x USB-C 3.2 Gen1, 1x USB-A 3.2 Gen2, 1x USB 3.2 Gen1, 3x USB 2.0/1.1, Q-Flash Plus, RJ45, 2x SMA, 3x Audio Jacks - Network: Realtek WiFi 6E RTL8852CE + BT 5.3 - Form Factor: Mini-ITX - B650I AX

GIGABYTE Ultra Durable motherboards built with optimal components inside out provide the prime performance and timeless platform.

B650I AX

AMD Socket AM5:Supports AMD Ryzen 7000/ Ryzen 8000 Series Processors
Unparalleled Performance:5+2+1 Phases Digital VRM Solution
Dual Channel DDR5:2*SMD DIMMs with AMD EXPO & Intel XMP Memory Module Support
SuperSpeed Storage:PCIe 4.0 x4 M.2 Connector
EZ-Latch:PCIe x16 Slot with Quick Release Design
Fast Networks:Wi-Fi 6E 802.11ax & 2.5GbE LAN
Extended Connectivity:DP, HDMI
Smart Fan 6:Features Multiple Temperature Sensors, Hybrid Fan Headers with FAN STOP
Q-Flash Plus:Update BIOS Without Installing the CPU, Memory and Graphics Card

Overview

1 - Solid Pin CPU Power Connector

2 - 5+2+1 Digital VRM Design
- PCle 4.0 Ready Mid Loss PCB

3 - 1*PCIe 4.0 x4 M.2 connector

4 - DisplayPort, HDMI

5 - USB 3.2 Gen1

6 - Q-FLASH PLUS Button

7 - USB 3.2 Gen1 Type-C+
USB 3.2 Gen 2 Type A

8 - 2.5GbE LAN

9 - 802.11 ax Wi-Fi

10 - Dual Channel SMD DDR5 Memory

11 - Socket AM5 Supports
AMD Ryzen Series Processors

12 - Smart Fan 6
3*PWM/DC Fan Headers
Dual Fan Curve Mode

13 - RGB FUSION
1*Addressable LED Header
1*RGB LED Header

14 - PCIe EZ-Latch

15 - 1*PCIe 4.0 x16 slot

Durable Performance

GIGABYTE Ultra Durable motherboards built with optimal components inside out provide the prime performance and timeless platform.

Digital VRM Design

5+2+1 Phases Digital VRM Solution with high performance DrMOS

GIGABYTE UD series motherboards use a 5+2+1 phases digital PWM + high performance DrMOS design to support AMD's new generation CPUs by offering incredible precision in delivering power to the motherboard's most power-hungry and energy-sensitive components as well as delivering enhanced system performance and ultimate hardware scalability.

DDR5 EXPO & XMP Overclocking Up to 6400 and Beyond*

GIGABYTE is offering a tested and proven platform that the memory overclocking capability is able up to 6400 and beyond. All users need to do for achieving this extreme memory performance boost is to ensure that their DDR5 memory modules are AMD EXPO/ Intel XMP capable, the EXPO/XMP function is activated and enabled on their GIGABYTE motherboard.

802.11ax Wi-Fi 6E

The latest Wireless solution 802.11ax Wi-Fi 6E with new dedicated 6GHz band, enables gigabit wireless performance, provides smooth video streaming, better gaming experience, few dropped connections and speeds up to 2.4Gbps. Moreover, Bluetooth 5 provides 4X range over BT 4.2 and with faster transmission.

First adopter on 2.5GbE LAN onboard

2X Faster than ever

-Adoption of 2.5G LAN provide up to 2.5 GbE network connectivity, with at least 2 times faster transfer speeds compared to general 1GbE networking, perfectly designed for gamers with ultimate online gaming experience.
-Support Multi-Gig(10/100/1000/2500Mbps) RJ-45 Ethernet

PCIe 4.0 Hardware Design

GIGABYTE A620 Motherboards are ready to work with the PCIe 4.0 devices which are expected to experience twice bandwidth than the current PCIe 3.0 devices. To reach the high speed and maintain good signal integrity, GIGABYTE R&D uses the low impedance PCB to provide the maximum performance.

EZ-Latch

Unlock the latch of the PCIe slot easily when remove the graphics card in the PCIe slot.

Q-Flash Plus

Update the BIOS easily without installing the CPU, memory and graphics card. With GIGABYTE Q-Flash Plus, you don't need to install the CPU, memory and graphics card nor enter the BIOS menu to flash the BIOS. Just download and save a new BIOS file (rename to gigabyte.bin) on the USB flash drive, then press the dedicated Q-Flash Plus button and you’re good to go!

STEP 1: Plug 24pin & 8pin power supply cable on motherboard

STEP 2: Download motherboard BIOS file and rename to ""gigabyte.bin"", save to USB flashdrive, and plug USB flashdrive into Q-Flash USB port

STEP 3: Press Q-Flash Plus button, and motherboard will start updating BIOS automatically.

Smart Fan 6

Smart Fan 6 contains several unique cooling features that ensure gaming PC maintain its performance while staying cool and quiet. Multiple fan headers can support PWM/DC fan and pump, and users can easily define each fan curve based on different temperature sensors across the board via intuitive user interface.

Cooling Features

High Current Support: Each fan headers support PWM and DC fan and Water Cooling Pump , and up to 24W (12V x 2A) with Over-Current Protection

Precision Control: Multiple temperature/fan speed control points for precise fan curve

Dual Curve Mode: Slope/Stair dual mode for different user scenario

Fan Stop: Fan can stop completely below users' specified temperature point

Smart Fan 6 BIOS UI

Improve fan curve UI: We increase control points from 5 to 7 and larger fan speed graph for precise and easier fan curve control.

Slope/Stair dual graph mode: Fan curve can be quickly switch with Slope and Stair modes for different user scenario. Slope is traditional and intuitive linear fan speed curve. With newly added Stair non-linear mode, fan keeps at same speed between specified temperature interval.

Manual Input: For advanced users, we provide fan speed manual input for more precise control.

EZ Tuning: Use can place 4 EZ Tuning points at rough temperature/fan speed, and Smart Fan 6 can quickly generate a fan curve.

Fan curve profile: Fan curve profile can be saved in BIOS ROM, profile will be kept after updating BIOS.
