GALAX GeForce RTX™ 5080 1-Click OC

16GB GDDR7 256-bit DP2.1b*3/HDMI 2.1b/DLSS 4

The GALAX GeForce RTX 5080 1-Click OC is a high-performance GPU based on NVIDIA’s Blackwell architecture. It features 10,752 CUDA cores, 16GB GDDR7 memory, and a 256-bit interface, delivering top-tier gaming and AI capabilities. With DLSS 4, ray tracing enhancements, and a boost clock of 2,640 MHz, it’s built for 4K gaming and content creation. It includes DisplayPort 2.1b & HDMI 2.1b outputs and requires a 16-pin power connector. Ideal for enthusiasts and professionals seeking cutting-edge graphics performance.

Description

• Powered by the NVIDIA Blackwell Architecture and DLSS 4
• Dedicated Tensor Cores
• Dedicated RT Cores
• Microsoft DirectX® 12 Ultimate
• GDDR7 Graphics Memory
• NVIDIA DLSS 4
• NVIDIA® App
• NVIDIA G-SYNC®
• NVIDIA GPU Boost™
• Game Ready and NVIDIA Studio Drivers
• DisplayPort 2.1b, HDMI 2.1b
• VR Ready
• To 1-Click OC, overclock, control ARGB and monitor GPU info of your graphics cards in-App, please make sure your mobile device and PC are connected with the same WiFi network.
• All photos, specifications, contents are used for reference only and are subject to change without notice. Actual products in different countries varies and are best to consult your local distributor / importer for confirmation.

Specification

GPU Engine Specs:

• CUDA Cores: 10752
• Boost Clock: 2625MHz
• 1-Click OC Clock: 2640MHz (by installing Xtreme Tuner Plus Software and using 1-Click OC)

Memory Specs:

• Memory Speed: 30 Gbps
• Standard Memory Config: 16GB GDDR7
• Memory Interface Width 256-bit
• Memory Bandwidth: 960 GB/sec

Feature Support:

• PCI-E 5.0
• Windows 10/11 64-bit

Fan Feature:

• 3 * 92mm
• WINGS 3.0 with Fan stop @ Idle (All Fans)

Display Support:

• DisplayPort 2.1b x 3, HDMI 2.1b x 1

Dimensions:

• Dimensions(with Bracket): 315*140.5*50.7mm
• Dimensions(without Bracket): 303*125*49.7mm (NVIDIA SFF-Ready)

In Box Accessories:

• 1-Click sync pro cable
• PCIe 1x 16-pin to 3x 8-pin adapter
• Metallic support stick
